Produktbeschreibung
Beschreibung:
* ColorMeter Pro is an innovation color measuring tool with powerful configuration to make color measurement easier and more professional;
* It support Bluetooth to connect with Android and ISO devices, ColorMeter Pro will take you into a new world of color management;
* It can be widely used to measure color value, color difference value and find similar color from color cards for printing industry, paint industry, textile industry, usw.
Merkmale:
1. Measure Color Value
Adopt international used D/8 (Diffused Illumination, 8 degree viewing) geometry andSCI mode to make measurement more accurate.
Adopt spectral sensor to provide reflectance data which make its performance much better than colorimeter.
To get correct L*a*b, L*Ch, RGB, Hex and other color value under light source D65 or D50.
It can measure whiteness index, yellowness index, color strength, color fastness, opacity and other 20 kinds of parameters with 26 kinds ofilluminants.
2. Measure Color Difference Value
“Pass” or “Fail”judgment can be seen from both instrument and APP.
ΔE *ab, ΔE * CH and other color difference formulas, display color difference value, color difference evaluation results.
Connect to App for color difference evaluation, color difference tolerance and parameters can be set in APP.
3. Portable and Massive Color Card Database
Bluetooth to connect with mobile phone APP to create database to upload the color shades from printing, malen, textile color cards.
No need to carry big and heavy color card, we can find color card database from Colormeter Pro APP and find the closed/similar color easier and faster.
4. Artificial Intelligence for Accurately Measure Color
AI-based color search engine for accurately measure color;
Color can be collected anywhere and anytime
5. Innovation Design for Auto Black and White Calibration
Auto instrument black and white calibration for easier and correct color test
APP will remind for calibration if instrument works for long time
From APP we can do manual calibration and set calibration interval.
6. Single Instrument for Test and Save Test Value
1.14 inches IPS display screen to show color information.
Data can be saved on instrument and instrument data can be synced into APP
7. Cloud database, more convenient to view and upload
Official color card databases are available.
Technical Specifications
* Modell: ColorMeter Pro
* Illumination and Viewing System: D/8, SCI (specular component included)
* Color Spaces and Indices:
Reflectance, CIE-Lab, CIE-LCh, HunterLab, CIE-Luv, XYZ, Yxy, RGB, Color Difference (ΔE*ab,ΔE*cmc,ΔE*94,ΔE*00), Whiteness Index (ASTM E313-00,ASTM E313 73,CIE/ISO,AATCC,Hunter,TaubeBergerStensby), Yellowness Index (ASTM D1925,ASTM E313-00,ASTM E313-73), Blackness Index(My,dM), Staining Fastness, Color Fastness, Tint(ASTM E313-00), Color Density CMYK(A,T,E,M),Metamerism Index Milm, Munsell, Opacity, Color Strength
* Light Source: LED (Full Wavelength Balanced LED Light Source)
* Measure Aperture: 8mm
* Wavelength Interval: 10nm
* Wavelength Range: 400-700nm
* Repeatability: ΔE≤0.1 (when a white tile is measured 30 times at 5-second intervals after calibration)
* Measurement Time: 1S
* Interface: USB, Bluetooth
*Illuminants:A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84
* Observer: 2° and 10°
* Display Screen: IPS Full Color Screen (135*240mm,1.14Zoll)
* Batterie: 4.2V / 760mAh, Rechargeable, 10,000 continuous tests
* Sprache: English and Chinese
* Calibration: Auto
* Software Support: Android, IOS, Windows
* Gewicht: About 90g
* Instrument Size:Diameter 31mm , Height 102mm
Wird vom Hersteller eingestellt : No
Verpackungsabmessungen : 9.84 X 3.94 X 3.94 Zoll; 2.2 Pfund
Datum zuerst verfügbar : April 1, 2018
Hersteller : CNYST
ASIN : B08DKM22YR
Herkunftsland : China
◆ Illumination and Viewing System: D/8, SCI (specular component included)
◆ Light Source: LED (Full Wavelength Balanced LED Light Source);Calibration: Auto
◆ Measure Aperture: 8mm;Display Screen: IPS Full Color Screen (135*240mm,1.14Zoll)
◆ Illuminants:A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84
◆ Repeatability: ΔE≤0.1 (when a white tile is measured 30 times at 5-second intervals after calibration)
1. How does a Lab Color Meter work?
A Lab Color Meter works by measuring the color of an object based on its reflectance of light. It measures the color in the Lab color space, which consists of three coordinates: L (lightness), a (green-red), and b (blue-yellow).
2. What is the difference between a Colorimeter and a Lab Color Meter?
A Colorimeter is a device used for measuring the color of an object, while a Lab Color Meter specifically measures color in the Lab color space. The Lab Color Meter provides more precise and detailed color information compared to a Colorimeter.
3. How can a Lab Color Meter help with color difference analysis?
A Lab Color Meter can help with color difference analysis by accurately measuring the color of two samples and calculating the color difference between them. This information is crucial for ensuring color consistency in manufacturing and quality control processes.
4. Can a Lab Color Meter measure chromatic values?
Ja, a Lab Color Meter can measure chromatic values, which are the color components of an object that determine its hue. By measuring the a and b coordinates in the Lab color space, the Lab Color Meter can provide detailed information about the chromatic properties of a sample.
5. How accurate are the color measurements taken by a Lab Color Meter?
Lab Color Meters are highly accurate devices that can provide precise measurements of color with minimal margin of error. The accuracy of the measurements can be affected by factors such as sample preparation and calibration of the device, but overall, Lab Color Meters are reliable tools for color analysis.
