Product Parameters
APG-Ⅲ molecular sieve is a new type of molecular sieve in the air separation unit, which is a kind of alkali metal silicon aluminate. Compared with ordinary 13X molecular sieve, its adsorption performance is improved by about 50%, and the adsorption effect of N2O is also more obvious at low partial pressure.13X type molecular sieve can adsorb the critical diameter of not more than 10A molecules.
|
Items
|
Quality Indicators
|
|
|
Type Of The Product
|
4 × 8 mesh
|
8 × 12 mesh
|
|
Nominal Diameter, (A)
|
10
|
10
|
|
Packing Density , (kg/m3)
|
640
|
640
|
|
Grain Diameter , (milímetros)
|
0.4-0.8
|
1.6-2.5
|
|
Crushing Resistance, N/ piece
|
≥80
|
≥25
|
|
Wear Rate, %
|
≤0.20
|
≤0.20
|
|
Static Water Adsorption *, %
|
≥29.00
|
≥29.00
|
|
Static Carbon Dioxide Adsorption**, %
|
≥19.50
|
≥19.50
|
|
Water Content Of Package (at time of shipment), %
|
≤1.0%
|
≤1.0%
|
|
adsorb molecular
|
Molecules with effective diameter < 10A
|
|
|
discharge molecular
|
The effective diameter of the discharge molecule is >10a, como(C4F9)3N
|
|
Chemical Formula:
Nax[(AlO2)X(SiO2)y].zH2O
Nax[(AlO2)X(SiO2)y].zH2O
Regeneration:
APG-Ⅲ molecular sieve can be purged or vacuumed for regeneration and reuse at elevated temperature. The degree of regeneration (dehydration) depends on the humidity and temperature of the purged air.
Packing:
APG-Ⅲ molecular sieve has 8×12 orders, 4 × 8 orders and 6 × 8 orders spherical form.Load and ship in sealed steel drums.
Remarks:The number of grams of water adsorbed per 100 g of activated adsorbent at a pressure of 17.5 mm hg and a temperature of 250C. ** The number of grams of carbon dioxide adsorbed per 100 grams of activated adsorbent at 250 mm Hg and 250C
Solicitud:
APG-Ⅲ molecular sieves are used for purifying raw materials with high impurity content in air separation units (removing H2O,CO2 and N2O at the same time), as well as some hydrocarbons.
Any molecule that can be adsorbed on 3A, 4A and 5A molecular sieves can be adsorbed on 13X type.In addition, 13X type can adsorb molecules with larger critical diameters, such as some aromatic hydrocarbons and branched hydrocarbon.
Any molecule that can be adsorbed on 3A, 4A and 5A molecular sieves can be adsorbed on 13X type.In addition, 13X type can adsorb molecules with larger critical diameters, such as some aromatic hydrocarbons and branched hydrocarbon.
